LMK20LUU | THK | Maxima Linear Bearing

₹ 4,523.08

₹ 3,833.12 (Excl. Tax)


Warranty

We provide a 1-year warranty from the date of purchase for new products. Additionally, surplus / used items come with a 30-day warranty.

Delivery and Shipping

We aim to process orders within 5-7 business days. Shipping options vary by location with tracking provided; international shipping available with customs duties responsibility on customers.


Enquire Now
Interested in this product? Submit your enquiry by entering your details.

Manufacturer Part Number (MPN)

LMK20LUU

Original Equipment Manufacturer

THK

Description

Inner Diameter (Shaft Diameter) 20 mm
Outer Diameter 32 mm
Length 80 mm
Flange Diameter 54 mm
Flange Thickness 8 mm
Mounting Hole Diameter 5.5 mm
Mounting Hole Pitch (PCD) 43 mm
Dynamic Load Rating 2,740 N
Static Load Rating 1,370 N
Seal Type UU (rubber seals on both ends)
Material Steel housing with synthetic resin retainer
Temperature Range -30°C to +80°C
