LC2K1201E7 | SCHNEIDER ELECTRIC | TeSys K Reversing Contactor - 3P - AC-3 <= 440 V 12 A - 1 NC - 48 V AC Coil

₹ 23,343.09

₹ 19,782.28 (Excl. Tax)

Warranty

We provide a 1-year warranty from the date of purchase for new products. Additionally, surplus / used items come with a 30-day warranty.

Delivery and Shipping

We aim to process orders within 5-7 business days. Shipping options vary by location with tracking provided; international shipping available with customs duties responsibility on customers.

Enquire Now
Interested in this product? Submit your enquiry by entering your details.

Manufacturer Part Number (MPN)

LC2K1201E7

Original Equipment Manufacturer

SCHNEIDER ELECTRIC

Description
Manufacturer Schneider Electric (TeSys K Series)
Device Type Reversing Contactor, 3‑Pole (3 NO power contacts)
Rated Current (Ie) 12 A (AC‑3 / ≤440 V)
Motor Rating ≈ 5.5 kW @ 400 V
Coil Voltage (Uc) 48 VAC, 50/60 Hz
Auxiliary Contacts 2 NC built‑in (signalling circuit)
Reversing Circuit Pre‑wired with mechanical interlock
Utilisation Category AC‑3 / AC‑3e, AC‑1, AC‑4
Short-Time Withstand (Icw) 115 A @ 1 s; 105 A @ 5 s; 100 A @ 10 s (power circuit)
Breaking Capacity 110 A @ 440 V / 690 V AC
Insulation Voltage (Ui) 690 V IEC; 600 V UL/CSA
Impulse Withstand (Uimp) 8 kV
Control Circuit Limits Operate: 0.8–1.15 × Uc; Drop‑out: 0.2–0.75 × Uc
Inrush / Hold‑In Power ≈ 30 VA / 4.5 VA @ 20 °C
Connections Screw-clamp terminals for 0.34–4 mm² (flexible/solid)
Tightening Torque 1.3 N·m (~11.5 lbf·in)
Operation / Release Time ≈ 10–20 ms
Mechanical Durability 5 million operations
Electrical Durability 1.3 million cycles @ 12 A AC‑3; 0.3 million @ 20 A AC‑1
Operating Rate Up to 3600 cycles/hour (AC‑3)
Shock / Vibration Shock: up to 15 g; vibration: 2–4 g per IEC 60068‑2‑27/6
Operating Temp. −25 °C to +50 °C
Storage Temp. −50 °C to +80 °C
Protection Rating IP20
Standards & Certifications IEC 60947‑4‑1; UL 60947‑4‑1; CSA C22.2; CE; CCC; EAC; CB; Green Premium / RoHS
Dimensions (H×W×D) 58 × 90 × 57 mm
Weight ≈ 0.39 kg
