SPARECRUX is an authorized distributor for HENSEL ELECTRIC

KV 7103 | HESNEL | Circuit Breaker Boxes IP 65

₹ 2,397.76

₹ 2,032.00 (Excl. Tax)

●   Available for backorder, with an estimated lead time of 8 to 12 weeks.

Warranty

We provide a 1-year warranty from the date of purchase for new products. Additionally, surplus / used items come with a 30-day warranty.

Delivery and Shipping

We aim to process orders within 5-7 business days. Shipping options vary by location with tracking provided; international shipping available with customs duties responsibility on customers.

Enquire Now
Interested in this product? Submit your enquiry by entering your details.

Manufacturer Part Number (MPN)

KV 7103

Original Equipment Manufacturer

HENSEL ELECTRIC

Description

KV 7103

  • 3 modules: 1 x 3 x 18 mm
  • 1-row
  • Knockouts: top and bottom walls 2x M20 each
  • Per PE/N number x cross section 1 x 25 mm², 4 x 4 mm² Cu, FIXCONNECT® terminal technology, for terminal technology refer to technical data
  • For the installation of DIN rail equipment up to 63 A, top hat profile 35 mm
  • With transparent lid, sealable
  • Locking device for hinged lid and sealing facility see accessories
  • With cable entry cover
  • Protective cover can be cut out
  • Degree of protection: IP 65
  • Colour: grey, RAL 7035

Technical Data

rated insulation voltage Ui = 400 V A.C.
power dissipation capability Pde = 10 watts at 30 K according to EN 60670-24
protection class II
material PS (Polystyrene)
width 102 mm
height 197 mm
depth 92 mm
weight 0,404 kg
Kv 7103 | Hesnel Circuit Breaker Boxes Ip 65
HENSEL ELECTRIC

KV 7103 | HESNEL | Circuit Breaker Boxes IP 65

₹ 2,032.00

KV 7103

Technical Data

rated insulation voltage Ui = 400 V A.C.
power dissipation capability Pde = 10 watts at 30 K according to EN 60670-24
protection class II
material PS (Polystyrene)
width 102 mm
height 197 mm
depth 92 mm
weight 0,404 kg
