SPARECRUX is NOT an authorized distributor for LAPP GROUP

KRT35-12 | LAPP GROUP | Tinned Copper With Inspection Hole

₹ 7,628.41

₹ 6,464.75 (Excl. Tax)

Warranty

We provide a 1-year warranty from the date of purchase for new products. Additionally, surplus / used items come with a 30-day warranty.

Delivery and Shipping

We aim to process orders within 5-7 business days. Shipping options vary by location with tracking provided; international shipping available with customs duties responsibility on customers.

Enquire Now
Interested in this product? Submit your enquiry by entering your details.

Manufacturer Part Number (MPN)

KRT35-12

Original Equipment Manufacturer

LAPP GROUP

Description
Specification Details
Features
  • With inspection hole (starting from 4 mm²)
  • High-quality electrolytic copper ensures good crimping quality
Application Range
  • KR: For fine and multi-wire copper conductors (class 2 and 5), cross-sectional range 0.75 – 10 mm²
  • KRT: For multi-wire copper conductors (class 2), cross-sectional range 10 – 1000 mm²
  • KRF: For fine wire copper conductors (class 2, 5 and 6), cross-sectional range 16 – 800 mm²
  • Mainly for connection to rails and copper connectors
  • Max. voltage: 48 kV
Norm References / Approvals UL file number: E205350
In combination with recommended crimp tool fulfills EN-IEC 61238-1, BS 4579-1, and VDE 0220-1
Classification ETIM 5 ETIM 5.0 Class-ID: EC001051
ETIM 5.0 Class-Description: Tube cable lug for copper conductors
Classification ETIM 6 ETIM 6.0 Class-ID: EC001051
ETIM 6.0 Class-Description: Tube cable lug for copper conductors
Material Tinned electrolytic copper (Cu/Sn4, tin surface 4 µm)
Temperature Range Up to +90°C working temperature
Max. +140°C
