H07V-K 1X120 GNYE | LAPP GROUP | Single Core; 1X120

₹ 2,387.73

₹ 2,023.50 (Excl. Tax)

Warranty

We provide a 1-year warranty from the date of purchase for new products. Additionally, surplus / used items come with a 30-day warranty.

Delivery and Shipping

We aim to process orders within 5-7 business days. Shipping options vary by location with tracking provided; international shipping available with customs duties responsibility on customers.

Enquire Now
Interested in this product? Submit your enquiry by entering your details.

Manufacturer Part Number (MPN)

H07V-K 1X120 GNYE

Original Equipment Manufacturer

LAPP GROUP

Description
Specification Details
Weight 1285 kg/km
Copper Index 1152.000 kg/km
Copper Index (lb) 7740.300 lb/10,000 ft
Single Core Packaging Type Depending on length
Nominal Voltage U0/U: 450/750 V AC rms according to IEC
Test Voltage 2.5 kV
Current Rating According to VDE 0298-4
Max. Conductor Resistance at 20°C 0.161 Ω/km
Harmonised Design H07V-K
Cable Dimension 1X120
Conductor Cross-Section 120 mm²
Conductor Material Bare Copper
Conductor Design IEC 60228 class 5: fine-wire
Number of Cores 1
Min. Outer Diameter 16.7 mm
Max. Outer Diameter 20.2 mm
Shape of Cable Round
Core Insulation Base Material Polyvinylchloride (PVC)
Application Area Fixed Installation
Minimum Bending Radius (Fixed Installation) 6 × outer diameter
Minimum Bending Radius in mm (Stationary) 121.2 mm
Minimum Bending Radius with Careful Bending 4 × outer diameter
Temperature (Fixed Installation) -40 °C to +70 °C
Installation Temperature Min. +5 °C
Installation Temperature Max. +70 °C
Storage Temperature Min. +5 °C
Storage Temperature Max. +40 °C
