FN2080-3-06 | SCHAFFNER | Power Line Filters

₹ 3,739.18

₹ 3,168.80 (Excl. Tax)

Warranty

We provide a 1-year warranty from the date of purchase for new products. Additionally, surplus / used items come with a 30-day warranty.

Delivery and Shipping

We aim to process orders within 5-7 business days. Shipping options vary by location with tracking provided; international shipping available with customs duties responsibility on customers.

Enquire Now
Interested in this product? Submit your enquiry by entering your details.

Manufacturer Part Number (MPN)

FN2080-3-06

Original Equipment Manufacturer

SCHAFFNER

Description
Attribute Details
Voltage AC 250
Nominal Frequency 50
Rated Current @ Ambient 3
Ambient Temperature 40
Electric
Leakage Current IEC60939 0.66
Power Loss 3.7
Resistance 470
Attenuation
Inductance L1 9.8
Inductance L2 160
Capacitance Cx1 0.47
Capacitance Cy1 4.7
CM Attenuation @ 150 kHz 39
DM Attenuation @ 150 kHz 33
Mechanic
Length 64.8
Width 49.8
Height 40.3
Volume 130
Weight 205
