SPARECRUX is NOT an authorized distributor for SEALMASTER

ER-23T | SEALMASTER | Bearing

₹ 18,151.23

₹ 15,382.40 (Excl. Tax)

Warranty

We provide a 1-year warranty from the date of purchase for new products. Additionally, surplus / used items come with a 30-day warranty.

Delivery and Shipping

We aim to process orders within 5-7 business days. Shipping options vary by location with tracking provided; international shipping available with customs duties responsibility on customers.

Enquire Now
Interested in this product? Submit your enquiry by entering your details.

Manufacturer Part Number (MPN)

ER-23T

Original Equipment Manufacturer

SEALMASTER

Description
Parameter Specification
Bore Type Straight
Bore Diameter 1‑7/16 in
Outside Diameter 2.8350 in
Internal Clearance Standard
Overall Width 1.7500 in
Bearing Type Ball Bearing
Outer Ring Width 0.9380 in
Duty Type Medium Duty
Inner Ring Width 1.7500 in
Locking Device Concentric Collar
Operating Temperature Range -20 to 220 °F
Fillet Radius 0.0400 in
Radial Dynamic Load Capacity 5782 lbs
Radial Static Load Capacity 3493 lbs
Bearing Material 52100 Bearing Steel
Cage Material PPS
Finish / Coating Black Oxide
Max RPM 6500 rpm
Retainer Type Land Riding Retainer
Seal Type Felt Labyrinth Seal
Expansion Type Non-Expansion Bearing (Fixed)
Series ER-T
Precision Rating ABEC 1
