SPARECRUX is NOT an authorized distributor for SEALMASTER

ER-210TMC | SEALMASTER | Bearing

₹ 28,327.67

₹ 24,006.50 (Excl. Tax)

Warranty

We provide a 1-year warranty from the date of purchase for new products. Additionally, surplus / used items come with a 30-day warranty.

Delivery and Shipping

We aim to process orders within 5-7 business days. Shipping options vary by location with tracking provided; international shipping available with customs duties responsibility on customers.

Enquire Now
Interested in this product? Submit your enquiry by entering your details.

Manufacturer Part Number (MPN)

ER-210TMC

Original Equipment Manufacturer

SEALMASTER

Description
Parameter Specification
Bore Type Straight
Bore Diameter 50 mm
Outside Diameter 90 mm
Internal Clearance Standard
Overall Width 2.0945 in
Bearing Type Ball Bearing
Outer Ring Width 28.6 mm
Duty Type Medium Duty
Inner Ring Width 53.2 mm
Locking Device Concentric Collar
Operating Temperature Range -20 to 220 °F
Fillet Radius 0.0620 in
Radial Dynamic Load Capacity 7889 lbs
Radial Static Load Capacity 5216 lbs
Bearing Material 52100 Bearing Steel
Cage Material PPS
Finish / Coating Black Oxide
Max RPM 3550 rpm
Retainer Type Land Riding Retainer
Seal Type Single Lip Contact Seal
Expansion Type Non-Expansion Bearing (Fixed)
Series ER-T
Precision Rating ABEC 1
Misalignment Angle None
Housing Type Insert (ER Style)
Insert Material 52100 Bearing Steel, Black Oxided
Lubricant / Lubrication Type Lithium Complex NLGI 2 Grease
CAD Drawing Click here
Manufacturer Catalog Number ER-210TMC
Manufacturer Product Page Click here
Manufacturer Catalog Click here
Manufacturer UPC Number 662461254035
UPC_NO 662461254035
SEALMASTER
