SPARECRUX is NOT an authorized distributor for OMRON

E6CP-AG5C-C | OMRON | Rotary Encoder

₹ 47,041.82

₹ 39,865.95 (Excl. Tax)

Warranty

We provide a 1-year warranty from the date of purchase for new products. Additionally, surplus / used items come with a 30-day warranty.

Delivery and Shipping

We aim to process orders within 5-7 business days. Shipping options vary by location with tracking provided; international shipping available with customs duties responsibility on customers.

Enquire Now
Interested in this product? Submit your enquiry by entering your details.

Manufacturer Part Number (MPN)

E6CP-AG5C-C

Original Equipment Manufacturer

OMRON

Description
Parameter Specification
Encoder Technology Optical
Encoder Resolution 256 PPR
Orientation Horizontal
Encoder Output Gray Code
Product Range E6CP-A
Shaft Type D Type Flatted End
Shaft Diameter 6 mm
Supply Voltage Max 24 V
Operating Temperature Max 55°C
Termination 13 Pin Connector
Encoder Type Absolute
No. of Detents 0 Detents
Push Switch Without Push Switch
Encoder Mounting Servo Mount
Rotational Speed Max 1000 rpm
Shaft Length 10 mm
Supply Voltage Min 12 V
Operating Temperature Min -10°C
IP Rating IP50
OMRON

E6CP-AG5C-C | OMRON | Rotary Encoder

₹ 39,865.95
Parameter Specification
Encoder Technology Optical
Encoder Resolution 256 PPR
Orientation Horizontal
Encoder Output Gray Code
Product Range E6CP-A
Shaft Type D Type Flatted End
Shaft Diameter 6 mm
Supply Voltage Max 24 V
Operating Temperature Max 55°C
Termination 13 Pin Connector
Encoder Type Absolute
No. of Detents 0 Detents
Push Switch Without Push Switch
Encoder Mounting Servo Mount
Rotational Speed Max 1000 rpm
Shaft Length 10 mm
Supply Voltage Min 12 V
Operating Temperature Min -10°C
IP Rating IP50
