E2A-M18KN16-M1-B1 | OMRON | Proximity Sensor

₹ 10,827.59

₹ 9,175.92 (Excl. Tax)


Warranty

We provide a 1-year warranty from the date of purchase for new products. Additionally, surplus / used items come with a 30-day warranty.

Delivery and Shipping

We aim to process orders within 5-7 business days. Shipping options vary by location with tracking provided; international shipping available with customs duties responsibility on customers.


Enquire Now
Interested in this product? Submit your enquiry by entering your details.

Manufacturer Part Number (MPN)

E2A-M18KN16-M1-B1

Original Equipment Manufacturer

OMRON

Description

Specification Value
Body Material Brass
Housing Material Brass
Mount Flush, Panel
Number of Pins 4
Current Rating 10 mA
Max Operating Temperature 70 °C
Max Supply Voltage 32 V
Max Supply Voltage (DC) 32 V
Min Operating Temperature -40 °C
Min Supply Voltage 10 V
Min Supply Voltage (DC) 10 V
Operating Supply Current 10 mA
Operating Supply Voltage 24 V
Response Frequency 400 Hz
Sensing Distance 16 mm
Sensing Method Inductive
Shielding Unshielded
Switching Current 200 mA
Switching Frequency 400 Hz
Termination Connector
