SPARECRUX is NOT an authorized distributor for FESTO

DSBG-125-325-PPVA-N3 | FESTO | ISO Cylinder

₹ 44,255.29

₹ 37,504.48 (Excl. Tax)


Warranty

We provide a 1-year warranty from the date of purchase for new products. Additionally, surplus / used items come with a 30-day warranty.

Delivery and Shipping

We aim to process orders within 5-7 business days. Shipping options vary by location with tracking provided; international shipping available with customs duties responsibility on customers.


Enquire Now
Interested in this product? Submit your enquiry by entering your details.

Manufacturer Part Number (MPN)

DSBG-125-325-PPVA-N3

Original Equipment Manufacturer

FESTO

Description

Parameter Specification
Stroke 1 mm ... 2800 mm
Piston diameter 125 mm
Piston rod thread M27x2
Cushioning Pneumatic cushioning, adjustable at both ends
Mounting position optional
Conforms to standard ISO 15552
Piston-rod end Male thread
Design Piston
Piston rod Tie rod
Cylinder barrel
Position detection Via proximity switch
Ambient temperature -20 °C ... 80 °C
Impact energy in end positions 2.5 J
Cushioning length 45 mm
Theoretical force at 0.6 MPa (6 bar, 87 psi), return stroke 6881 N
Theoretical force at 0.6 MPa (6 bar, 87 psi), advance stroke 7363 N
Moving mass for 0 mm stroke 2245 g
Additional moving mass per 10 mm stroke 63 g
Basic weight for 0 mm stroke 6611 g
FESTO

DSBG-125-325-PPVA-N3 | FESTO | ISO Cylinder

₹ 37,504.48
Parameter Specification
Stroke 1 mm ... 2800 mm
Piston diameter 125 mm
Piston rod thread M27x2
Cushioning Pneumatic cushioning, adjustable at both ends
Mounting position optional
Conforms to standard ISO 15552
Piston-rod end Male thread
Design Piston
Piston rod Tie rod
Cylinder barrel
Position detection Via proximity switch
Ambient temperature -20 °C ... 80 °C
Impact energy in end positions 2.5 J
Cushioning length 45 mm
Theoretical force at 0.6 MPa (6 bar, 87 psi), return stroke 6881 N
Theoretical force at 0.6 MPa (6 bar, 87 psi), advance stroke 7363 N
Moving mass for 0 mm stroke 2245 g
Additional moving mass per 10 mm stroke 63 g
Basic weight for 0 mm stroke 6611 g
