SPARECRUX is NOT an authorized distributor for SCHNEIDER ELECTRIC

CAD32F7 | SCHNEIDER ELECTRIC | TeSys D Control Relay - 3 NO + 2 NC - <= 690 V - 110 V AC Standard Coil

₹ 5,857.23

₹ 4,963.75 (Excl. Tax)


Warranty

We provide a 1-year warranty from the date of purchase for new products. Additionally, surplus / used items come with a 30-day warranty.

Delivery and Shipping

We aim to process orders within 5-7 business days. Shipping options vary by location with tracking provided; international shipping available with customs duties responsibility on customers.


Enquire Now
Interested in this product? Submit your enquiry by entering your details.

Manufacturer Part Number (MPN)

CAD32F7

Original Equipment Manufacturer

SCHNEIDER ELECTRIC

Description

Product Name TeSys CAD
Product or Component Type Control relay
Device Short Name CAD
Contactor Application Control circuit
Control Circuit Type AC at 50/60 Hz
Control Circuit Voltage [Uc] 110 V AC 50/60 Hz
Mechanical Durability 30 Mcycles
Maximum Operating Rate 180 cyc/mn
Inrush Power in VA 70 VA 50 Hz (at 20 °C)
Hold-in Power Consumption in VA 8 VA 50 Hz (at 20 °C)
Minimum Switching Voltage 17 V
Minimum Switching Current 5 mA
Height 77 mm
Width 45 mm
Depth 84 mm
Net Weight 0.58 kg
SCHNEIDER ELECTRIC

CAD32F7 | SCHNEIDER ELECTRIC | TeSys D Control Relay - 3 NO + 2 NC - <= 690 V - 110 V AC Standard Coil

₹ 4,963.75
Product Name TeSys CAD
Product or Component Type Control relay
Device Short Name CAD
Contactor Application Control circuit
Control Circuit Type AC at 50/60 Hz
Control Circuit Voltage [Uc] 110 V AC 50/60 Hz
Mechanical Durability 30 Mcycles
Maximum Operating Rate 180 cyc/mn
Inrush Power in VA 70 VA 50 Hz (at 20 °C)
Hold-in Power Consumption in VA 8 VA 50 Hz (at 20 °C)
Minimum Switching Voltage 17 V
Minimum Switching Current 5 mA
Height 77 mm
Width 45 mm
Depth 84 mm
Net Weight 0.58 kg
