CA2KN22F7 | SCHNEIDER ELECTRIC | TeSys K Control Relay - 2 NO + 2 NC - <= 690 V - 110 V AC Coil

₹ 5,474.27

₹ 4,639.21 (Excl. Tax)

Warranty

We provide a 1-year warranty from the date of purchase for new products. Additionally, surplus / used items come with a 30-day warranty.

Delivery and Shipping

We aim to process orders within 5-7 business days. Shipping options vary by location with tracking provided; international shipping available with customs duties responsibility on customers.

Enquire Now
Interested in this product? Submit your enquiry by entering your details.

Manufacturer Part Number (MPN)

CA2KN22F7

Original Equipment Manufacturer

SCHNEIDER ELECTRIC

Description
Manufacturer Schneider Electric (TeSys K series)
Device Type Control Relay, 4‑pole (2 NO + 2 NC)
Control Coil Voltage 110 V AC, 50/60 Hz
Load Voltage ≤ 690 V AC, ≤ 400 Hz
Thermal Current (Ith) 10 A at ≤ 50 °C
Making Capacity (Irms) 110 A per IEC 60947
Recommended Fuse 10 A gG (IEC/VDE)
Insulation Voltage (Ui) 690 V IEC/BS, 600 V CSA, 750 V VDE
Mounting DIN‑rail or panel mount
Terminal Type Screw clamp terminals for solid/flexible cables 0.34–4 mm², torque 1.3 N·m
Operating Time Coil ON: 5‑15 ms (NC opens), 10‑20 ms (NO closes); Coil OFF: 15‑25 ms (NC closes)
Dissipation & Power Inrush 30 VA; Hold-in 4.5 VA; Heat dissipation ~1.3 W
Minimum Switching 17 V / 5 mA
Mechanical Durability 10 million cycles
Operating Rate 10,000 cycles/hour
Protection Rating IP2x
Dimensions (H×W×D) 58 × 45 × 57 mm
Weight ≈ 0.18 kg
Operating Temp. −25 °C to +50 °C; Storage −50 °C to +80 °C
Standards & Certifications IEC 60947; BS 5424; VDE 0660; NF C 63‑140; UL, CSA certified; Green Premium, RoHS compliant
