C96SD40-25 | SMC CORPORATION | Tie-Rod Cylinder

₹ 11,362.88

₹ 9,629.56 (Excl. Tax)

Warranty

We provide a 1-year warranty from the date of purchase for new products. Additionally, surplus / used items come with a 30-day warranty.

Delivery and Shipping

We aim to process orders within 5-7 business days. Shipping options vary by location with tracking provided; international shipping available with customs duties responsibility on customers.

Enquire Now
Interested in this product? Submit your enquiry by entering your details.

Manufacturer Part Number (MPN)

C96SD40-25

Original Equipment Manufacturer

SMC CORPORATION

Description
Feature Details
Series CP96
Type Double-acting, single rod
Bore Size 40 mm
Stroke Length 25 mm
Mounting Type Standard (basic), foot, front/rear flange, clevis, trunnion
Operating Pressure 0.05 to 1.0 MPa
Proof Pressure 1.5 MPa
Temperature Range -20°C to +70°C (without auto switch); -10°C to +60°C (with auto switch)
Lubrication Non-lube (factory lubricated)
Cushion Air cushion and bumper cushion
Piston Speed 50 to 1000 mm/s
Auto Switch Mounting Slide-in type (M9, A9, CNOMO grooves on all four sides)
Applications General industrial automation, robotics, material handling
