C60H C10 | SCHNEIDER ELECTRIC | Miniature Circuit Breaker

₹ 1,970.72

₹ 1,670.10 (Excl. Tax)


Warranty

We provide a 1-year warranty from the date of purchase for new products. Additionally, surplus / used items come with a 30-day warranty.

Delivery and Shipping

We aim to process orders within 5-7 business days. Shipping options vary by location with tracking provided; international shipping available with customs duties responsibility on customers.


Enquire Now
Interested in this product? Submit your enquiry by entering your details.

Manufacturer Part Number (MPN)

C60H C10

Original Equipment Manufacturer

SCHNEIDER ELECTRIC

Description

Poles 1P or 2P (model dependent)
Rated Current 10 A
Tripping Curve Type C (moderate inrush tolerance)
Rated Voltage Up to 500 V DC or 240/415 V AC
Breaking Capacity (DC) Up to 20 kA at 220 V DC for 2-pole version (A9N61528)
Width 2 modules (~18 mm) per pole
IP Rating IP20 (used within enclosures for compliance)
Features VisiTrip indication, padlockable OFF position
Endurance ~20,000 mechanical cycles, ~3,000 electrical cycles (DC)
Mounting Clip-on DIN-rail, top/bottom connection
Operating Range –25 °C to +70 °C
Standards IEC 60947-2, IEC 60898-1 (AC), EN 60947-2 (DC)
