SPARECRUX is NOT an authorized distributor for SCHNEIDER ELECTRIC

ATV12H018M2 | SCHNEIDER ELECTRIC | Variable speed drive, Altivar 12, 0.18kW, 0.25hp, 200 to 240V, 1 phase

₹ 21,702.97

₹ 18,392.35 (Excl. Tax)

Warranty

We provide a 1-year warranty from the date of purchase for new products. Additionally, surplus / used items come with a 30-day warranty.

Delivery and Shipping

We aim to process orders within 5-7 business days. Shipping options vary by location with tracking provided; international shipping available with customs duties responsibility on customers.

Enquire Now
Interested in this product? Submit your enquiry by entering your details.

Manufacturer Part Number (MPN)

ATV12H018M2

Original Equipment Manufacturer

SCHNEIDER ELECTRIC

Description
Manufacturer Schneider Electric (Altivar 12 Series)
Device Type Variable Frequency Drive (VFD), single‑phase
Rated Power 0.18 kW (0.25 HP)
Supply Voltage 200…240 V AC (±15 %) single‑phase, 50/60 Hz
Output Voltage 3‑phase 200…240 V AC
Rated Output Current ≈ 2.8 A @ 240 V (heavy duty), 3.4 A @ 200 V
Speed Range 0.1…400 Hz
Motor Control Sensorless flux vector control, PID regulation
EMC Filter Integrated (compliance with applicable EMC standards)
Communication Protocol Modbus over RS‑485
Inputs / Outputs Digital inputs: up to 4; Analog inputs: 1; Digital outputs: up to 2; Analog output: 1
Programming Interface Built-in keypad; PC via USB/Modbus
Mounting Wall or baseplate mounting, IP20
Operating Temperature −10 °C to +40 °C
Weight ≈ 0.9 kg (2.175 lb)
Ingress Protection IP20
Certifications RoHS, CE, UL, CSA compliant
