A9N2P16C | SCHNEIDER ELECTRIC | Schneider Electric Acti9 MCB A9N2P16C, 16Amp 2 Pole MCB, C Curve, 10000A (10kA) White Color Miniature Circuit Breaker

₹ 1,121.00

₹ 950.00 (Excl. Tax)


Warranty

We provide a 1-year warranty from the date of purchase for new products. Additionally, surplus / used items come with a 30-day warranty.

Delivery and Shipping

We aim to process orders within 5-7 business days. Shipping options vary by location with tracking provided; international shipping available with customs duties responsibility on customers.


Enquire Now
Interested in this product? Submit your enquiry by entering your details.

Manufacturer Part Number (MPN)

A9N2P16C

Original Equipment Manufacturer

SCHNEIDER ELECTRIC

Description

Model A9N2P16C
Series Acti 9 xC60
Type Miniature Circuit Breaker (MCB)
Poles 2
Rated Current 16 A
Tripping Curve C
Breaking Capacity 10 kA
Rated Voltage 240 V AC
Mounting DIN rail
Standards Compliance EN/IEC 60898-1
Dimensions 85mm (H) x 36mm (W) x 77.5mm (D)
Weight 0.215 kg
Color White
Durability Mechanical and electrical durability of 20,000 cycles
Terminal Capacity 16 mm² flexible, 25 mm² rigid (bottom); Biconnect (top)
Wire Stripping Length 13 mm
Tightening Torque 2 N·m
Earth Leakage Protection Separate block
Compatibility C60 accessories, C60 auxiliary
