A9F74340 | SCHNEIDER ELECTRIC | 3-Pole 40A Miniature Circuit Breaker, C Curve

₹ 21,032.12

₹ 17,823.83 (Excl. Tax)

Warranty

We provide a 1-year warranty from the date of purchase for new products. Additionally, surplus / used items come with a 30-day warranty.

Delivery and Shipping

We aim to process orders within 5-7 business days. Shipping options vary by location with tracking provided; international shipping available with customs duties responsibility on customers.

Enquire Now
Interested in this product? Submit your enquiry by entering your details.

Manufacturer Part Number (MPN)

A9F74340

Original Equipment Manufacturer

SCHNEIDER ELECTRIC

Description
Product Range Acti9 iC60N Miniature Circuit Breaker
Poles 3‑Pole (3P)
Rated Current (In) 40 A
Trip Curve C‑curve (thermal‑magnetic)
Breaking Capacity (Icu) 36 kA @ 12–60 V AC; 20 kA @ 220–240 V AC; 10 kA @ 380–415 V AC; 6 kA @ 440 V AC
10 kA @ ≤180 V DC; 6 kA Icn @ 400 V AC (residential)
Rated Insulation Voltage (Ui) 500 V AC
Impulse Withstand Voltage (Uimp) 6 kV
Magnetic Trip Limit ≈ 8 × In ±20%
Utilisation Category Category A per IEC/EN 60947-2
Mechanical Durability ≈ 20,000 cycles
Electrical Durability ≈ 10,000 cycles
Mounting Fixed support, DIN‑rail compatible (6 × 9 mm pitches)
Terminal Connections Single terminal, top or bottom, 1–35 mm² rigid / 1–25 mm² flexible wires; torque ≈ 3.5 N·m
IP Protection IP20 (basic); IP40 in enclosure
Operating Temperature −35 °C to +70 °C
Colour White (RAL 9003)
Weight ≈ 0.375 kg
Standards & Certifications EN/IEC 60898‑1, EN/IEC 60947‑2; Pollution Degree 3; Overvoltage Category IV
