750-975 | WAGO | RJ45 Ethernet Connector, IP20, 10/100 Mbps, Field Assembly

₹ 4,039.13

₹ 3,422.99 (Excl. Tax)

Warranty

We provide a 1-year warranty from the date of purchase for new products. Additionally, surplus / used items come with a 30-day warranty.

Delivery and Shipping

We aim to process orders within 5-7 business days. Shipping options vary by location with tracking provided; international shipping available with customs duties responsibility on customers.

Enquire Now
Interested in this product? Submit your enquiry by entering your details.

Manufacturer Part Number (MPN)

750-975

Original Equipment Manufacturer

WAGO

Description
Property Specification
Connection type RJ-45 plug
Pole number 8
Cable connection direction to mating direction 0°
Communication/Fieldbus ETHERNET
Code TIA-568A
Transmission rate 1000 Mbit/s
Insulation resistance (100 V) > 1 GΩ
Contact resistance (Wire – IDC) < 1 mΩ; (Strand – IDC) < 5 mΩ
Width 14 mm
Height 14 mm
Depth 59 mm
Shield Brass (CuZn); hot-dip tinned 3 μm; Shield contact: large surface >180°
Connection requirement (permissible cable type) Cat. 5e
Connectable sheathed cable diameter 4.5 – 8 mm
Housing material Plastic
Contact material Bronze (CuSn6)
Contact plating > 1.2 µm gold over 1.2 µm nickel
Mating cycles (max.) 1,000
Weight 10 g
Color Light gray
