SPARECRUX is NOT an authorized distributor for WAGO

750-610 | WAGO | 24 VDC Power Supply with Fuse Holder and Diagnostics

₹ 13,250.36

₹ 11,229.12 (Excl. Tax)


Warranty

We provide a 1-year warranty from the date of purchase for new products. Additionally, surplus / used items come with a 30-day warranty.

Delivery and Shipping

We aim to process orders within 5-7 business days. Shipping options vary by location with tracking provided; international shipping available with customs duties responsibility on customers.


Enquire Now
Interested in this product? Submit your enquiry by entering your details.

Manufacturer Part Number (MPN)

750-610

Original Equipment Manufacturer

WAGO

Description

Property Value
Signal Type Voltage
Signal Type (Voltage) 24 VDC
Supply Voltage (System) 5 VDC; via data contacts
Supply Voltage (Field) 24 VDC (-25 … +30 %); via power jumper contacts
Power Supply Details Power via CAGE CLAMP® connection; transmission (field-side) via spring contact
Current Consumption (5 V System Supply) 5 mA
Current Carrying Capacity (Power Jumper Contacts) 6.3 A
Number of Outgoing Power Jumper Contacts 3
Width 12 mm / 0.472 inches
Height 100 mm / 3.937 inches
Depth 69.8 mm / 2.748 inches
Depth from Upper-Edge of DIN-Rail 62.6 mm / 2.465 inches
Mounting Type DIN-35 rail
Pluggable Connector Fixed
Housing Material Polycarbonate; Polyamide 6.6
Fire Load 1.398 MJ
Weight 46.8 g
