750-601 | WAGO | Power Supply 24 VDC with Fuse Holder

₹ 9,654.84

₹ 8,182.07 (Excl. Tax)


Warranty

We provide a 1-year warranty from the date of purchase for new products. Additionally, surplus / used items come with a 30-day warranty.

Delivery and Shipping

We aim to process orders within 5-7 business days. Shipping options vary by location with tracking provided; international shipping available with customs duties responsibility on customers.


Enquire Now
Interested in this product? Submit your enquiry by entering your details.

Manufacturer Part Number (MPN)

750-601

Original Equipment Manufacturer

WAGO

Description

Parameter Specification
Signal type Voltage
Signal type (voltage) 24 VDC
Supply voltage (system) 5 VDC; via data contacts
Supply voltage (field) 24 VDC (-25 … +30 %); via power jumper contacts (power supply via CAGE CLAMP® connection; transmission (field-side supply voltage only) via spring contact
Current carrying capacity (power jumper contacts) 6.3 A
Connectable conductor materials Copper
Connection type Field supply
Solid conductor 0.08 … 2.5 mm² / 28 … 14 AWG
Fine-stranded conductor 0.08 … 2.5 mm² / 28 … 14 AWG
Strip length 8 … 9 mm / 0.31 … 0.35 inches
Connection technology: field supply 6 x CAGE CLAMP®
Width 12 mm / 0.472 inches
Height 100 mm / 3.937 inches
Depth 69.8 mm / 2.748 inches
Depth from upper-edge of DIN-rail 62.6 mm / 2.465 inches
Mounting type DIN-35 rail
Pluggable connector Fixed
Color Light gray
Housing material Polycarbonate; polyamide 6.6
Fire load 1.383 MJ
Weight 46.5 g
Conformity marking CE
