750-502 | WAGO | 2-channel Digital Output, 24 VDC, 2.0 A

₹ 12,444.47

₹ 10,546.16 (Excl. Tax)

Warranty

We provide a 1-year warranty from the date of purchase for new products. Additionally, surplus / used items come with a 30-day warranty.

Delivery and Shipping

We aim to process orders within 5-7 business days. Shipping options vary by location with tracking provided; international shipping available with customs duties responsibility on customers.

Enquire Now
Interested in this product? Submit your enquiry by entering your details.

Manufacturer Part Number (MPN)

750-502

Original Equipment Manufacturer

WAGO

Description
Number of digital outputs 2
Total number of channels (module) 2
Signal type Digital
Signal type (voltage) 24 VDC
Actuator connection 2 x (2-wire, 3-wire, 4-wire)
Output characteristic high-side switching
Output current per channel 2A
Output current short-circuit-protected
Load type Resistive, inductive, lamp load
Short-circuit limitation (typ.) PWM 35A
Switching frequency (max.) 2.5 kHz
Inductive load switch-off energy dissipation (max.) 0.14J
Output data width (internal) max. 2Bit
Supply voltage (system) 5 VDC; via data contacts
Current consumption (5 V system supply) 3.5mA
