750-470/005-000 | WAGO | 2-Ch AI, 0–20 mA SE, 12-bit

₹ 41,477.00

₹ 35,150.00 (Excl. Tax)

Warranty

We provide a 1-year warranty from the date of purchase for new products. Additionally, surplus / used items come with a 30-day warranty.

Delivery and Shipping

We aim to process orders within 5-7 business days. Shipping options vary by location with tracking provided; international shipping available with customs duties responsibility on customers.

Enquire Now
Interested in this product? Submit your enquiry by entering your details.

Manufacturer Part Number (MPN)

750-470/005-000

Original Equipment Manufacturer

WAGO

Description
Specification Details
Number of Analog Inputs 2
Total Number of Channels (Module) 2
Signal Type Current
Signal Type (Current) 0 … 20 mADC
Sensor Connection 2 x (2-wire, 3-wire)
Input Filter Frequency (Analog) 60 Hz
Connection Technology: I/O 8 x CAGE CLAMP®
Connectable Conductor Materials Copper
Connection Type Inputs/Outputs
Width 12 mm / 0.472 inches
Height 100 mm / 3.937 inches
Depth 69.8 mm / 2.748 inches
Mounting Type DIN-35 rail
Pluggable Connector Fixed
Color Light gray
Housing Material Polycarbonate; polyamide 6.6
Fire Load 0.754 MJ
Weight 52 g
Conformity Marking CE
