7212 CDGB/P4A | SKF | Super-Precision Angular Contact Ball Bearing (60x110x22 mm)

₹ 0.00

₹ 0.00 (Excl. Tax)

Warranty

We provide a 1-year warranty from the date of purchase for new products. Additionally, surplus / used items come with a 30-day warranty.

Delivery and Shipping

We aim to process orders within 5-7 business days. Shipping options vary by location with tracking provided; international shipping available with customs duties responsibility on customers.

Enquire Now
Interested in this product? Submit your enquiry by entering your details.

Manufacturer Part Number (MPN)

7212 CDGB/P4A

Original Equipment Manufacturer

SKF

Description
Parameter Value / Description
Brand SKF
Bearing Type Single-row angular contact ball bearing (super precision)
Model / Series 7212 CDGB/P4A
Inner Diameter (d) 60 mm
Outer Diameter (D) 110 mm
Width / Thickness (B) 22 mm
Contact Angle 15° (normal contact, two‑point)
Design / High-capacity Prefix “CD” High-capacity design (D)
Matching Designation “GB” Universally matchable (moderate preload face-to-face or back-to-back)
Accuracy / Tolerance Class “P4A” High precision class (above standard P4)
Static Load Rating (C₀) 46.5 kN
Dynamic Load Rating (C) 57.2 kN
Weight ~1.2 kg
Matching / Arrangement Capability Can be used in matched arrangements without shims within preload range
Usage / Purpose High-speed, high-precision applications requiring combined radial + axial load capability
SKF

7212 CDGB/P4A | SKF | Super-Precision Angular Contact Ball Bearing (60x110x22 mm)

₹ 0.00
Parameter Value / Description
Brand SKF
Bearing Type Single-row angular contact ball bearing (super precision)
Model / Series 7212 CDGB/P4A
Inner Diameter (d) 60 mm
Outer Diameter (D) 110 mm
Width / Thickness (B) 22 mm
Contact Angle 15° (normal contact, two‑point)
Design / High-capacity Prefix “CD” High-capacity design (D)
Matching Designation “GB” Universally matchable (moderate preload face-to-face or back-to-back)
Accuracy / Tolerance Class “P4A” High precision class (above standard P4)
Static Load Rating (C₀) 46.5 kN
Dynamic Load Rating (C) 57.2 kN
Weight ~1.2 kg
Matching / Arrangement Capability Can be used in matched arrangements without shims within preload range
Usage / Purpose High-speed, high-precision applications requiring combined radial + axial load capability
