SPARECRUX is NOT an authorized distributor for NTN

6912LLU | NTN | Single Row Deep Groove Ball Bearings

₹ 245.19

₹ 207.79 (Excl. Tax)


Warranty

We provide a 1-year warranty from the date of purchase for new products. Additionally, surplus / used items come with a 30-day warranty.

Delivery and Shipping

We aim to process orders within 5-7 business days. Shipping options vary by location with tracking provided; international shipping available with customs duties responsibility on customers.


Enquire Now
Interested in this product? Submit your enquiry by entering your details.

Manufacturer Part Number (MPN)

6912LLU

Original Equipment Manufacturer

NTN

Description

NTN 6912LLU Deep Groove Ball Bearing Specifications
Brand NTN
Model 6912LLU
Category Deep Groove Ball Bearing
Material High Carbon Chromium Steel
Dimensions (mm) 60 x 85 x 13
Sealing Type Double Rubber Sealed (LLU)
Cage Type Pressed Steel
Radial Clearance CN (Normal)
Dynamic Load Rating (C) 16.4 kN
Static Load Rating (C₀) 14.3 kN
Fatigue Limit Load (Cu) 0.965 kN
Limiting Speed (Grease Lubrication) 4,300 RPM
Operating Temperature Range -25°C to +110°C
Weight 0.193 kg
Shoulder Dimensions da min. 65 mm, da max. 66.5 mm, Da max. 80 mm
Fillet Radius 1 mm
Lubrication Grease Lubricated
Internal Clearance Normal (CN)
NTN

6912LLU | NTN | Single Row Deep Groove Ball Bearings

₹ 207.79
NTN 6912LLU Deep Groove Ball Bearing Specifications
Brand NTN
Model 6912LLU
Category Deep Groove Ball Bearing
Material High Carbon Chromium Steel
Dimensions (mm) 60 x 85 x 13
Sealing Type Double Rubber Sealed (LLU)
Cage Type Pressed Steel
Radial Clearance CN (Normal)
Dynamic Load Rating (C) 16.4 kN
Static Load Rating (C₀) 14.3 kN
Fatigue Limit Load (Cu) 0.965 kN
Limiting Speed (Grease Lubrication) 4,300 RPM
Operating Temperature Range -25°C to +110°C
Weight 0.193 kg
Shoulder Dimensions da min. 65 mm, da max. 66.5 mm, Da max. 80 mm
Fillet Radius 1 mm
Lubrication Grease Lubricated
Internal Clearance Normal (CN)
