6685 | FESTO | AND Gate ZK-PK-3

₹ 2,221.40

₹ 1,882.54 (Excl. Tax)


Warranty

We provide a 1-year warranty from the date of purchase for new products. Additionally, surplus / used items come with a 30-day warranty.

Delivery and Shipping

We aim to process orders within 5-7 business days. Shipping options vary by location with tracking provided; international shipping available with customs duties responsibility on customers.


Enquire Now
Interested in this product? Submit your enquiry by entering your details.

Manufacturer Part Number (MPN)

6685

Original Equipment Manufacturer

FESTO

Description

Parameter Specification
Valve Function AND function
Pneumatic Connection – Port 1 PK-3
Pneumatic Connection – Port 2 PK-3
Pneumatic Connection – Port 3 PK-3
Type of Mounting With through-hole
Standard Nominal Flow Rate 120 l/min (standardised to DIN 1343)
Operating Pressure 1.6 bar ... 8 bar
Ambient Temperature Range -10 °C ... 60 °C
Media Temperature Range -10 °C ... 60 °C
Operating Medium Compressed air to ISO 8573-1:2010 [7:-:-]
Nominal Size 2.4 mm
Mounting Position Optional
Material – Housing POM (Polyoxymethylene)
Material – Seals NBR (Nitrile Rubber)
Product Weight 10 g
LABS (PWIS) Conformity VDMA24364-B1/B2-L
Note on Operating & Pilot Medium Lubricated operation possible (mandatory if started)
Symbol 00991461
Note on Materials RoHS-compliant
