6202ZZNR/2AS | NTN | Single Row Deep Groove Ball Bearings

₹ 659.15

₹ 558.60 (Excl. Tax)


Warranty

We provide a 1-year warranty from the date of purchase for new products. Additionally, surplus / used items come with a 30-day warranty.

Delivery and Shipping

We aim to process orders within 5-7 business days. Shipping options vary by location with tracking provided; international shipping available with customs duties responsibility on customers.


Enquire Now
Interested in this product? Submit your enquiry by entering your details.

Manufacturer Part Number (MPN)

6202ZZNR/2AS

Original Equipment Manufacturer

NTN

Description

Specification Details
Brand NTN
d - Internal diameter 15 mm
D - External diameter 35 mm
B - Bearing/Inner ring width 11 mm
a min - Min position Groove 1,9 mm
a max - Max position groove 2,06 mm
rs - Min fillet radius 0,6 mm
rNs - Min fillet radius 0,5 mm
D3 - Max bottom groove diameter 33,17 mm
b min - Min groove width 1,35 mm
b max - Max groove width 1,65 mm
r0 max - Max bottom groove radius 0,4 mm
D4 max - Max outer diameter of assembled stop ring 39,7 mm
f - Stop ring thickness 1,12 mm
Snap ring reference R35
Radial clearance class CN
Mass 0,045 kg
