SPARECRUX is NOT an authorized distributor for SICK SENSORS

6048422 | SICK SENSORS | UM18-218165101 Ultrasonic Distance Sensor

₹ 20,401.73

₹ 17,289.60 (Excl. Tax)

●   Available for backorder, with an estimated lead time of 8 to 12 weeks.

Warranty

We provide a 1-year warranty from the date of purchase for new products. Additionally, surplus / used items come with a 30-day warranty.

Delivery and Shipping

We aim to process orders within 5-7 business days. Shipping options vary by location with tracking provided; international shipping available with customs duties responsibility on customers.

Enquire Now
Interested in this product? Submit your enquiry by entering your details.

Manufacturer Part Number (MPN)

6048422

Original Equipment Manufacturer

SICK SENSORS

Description
Operating range, limiting range 120 mm ... 1,000 mm, 1,300 mm
Target Natural objects
Resolution ≥ 0.2 mm
Repeatability ± 0.15 % 1)
Measurement accuracy ± 1 % 2)
Dimensions (W x H x D) 18 mm x 18 mm x 52.7 mm
Design Cylindrical
Sending axis Straight
Housing material Plastic (PBT, ultrasonic transducer: polyurethane foam, glass epoxy resin)
Weight 15 g
Thread size M18 x 1
Connection type Male connector, M12, 4-pin



SICK SENSORS 6048422 UM18-218165101 Ultrasonic Distance Sensor
SICK SENSORS

6048422 | SICK SENSORS | UM18-218165101 Ultrasonic Distance Sensor

₹ 17,289.60
Operating range, limiting range 120 mm ... 1,000 mm, 1,300 mm
Target Natural objects
Resolution ≥ 0.2 mm
Repeatability ± 0.15 % 1)
Measurement accuracy ± 1 % 2)
Dimensions (W x H x D) 18 mm x 18 mm x 52.7 mm
Design Cylindrical
Sending axis Straight
Housing material Plastic (PBT, ultrasonic transducer: polyurethane foam, glass epoxy resin)
Weight 15 g
Thread size M18 x 1
Connection type Male connector, M12, 4-pin
