6041811 | SICK SENSORS | VTE180-2P42482 Photoelectric Proximity Sensor

₹ 6,175.53

₹ 5,233.50 (Excl. Tax)

Get Best Price on WhatsApp

Product Description
Functional principle Photoelectric proximity sensor
Functional principle detail Energetic
Dimensions (W x H x D) 18 mm x 18 mm x 69.8 mm
Housing design (light emission) Cylindrical
Housing length 69.8 mm
Thread diameter (housing) M18 x 1
Optical axis Axial
Sensing range max. 1 mm ... 1,100 mm 1)
Sensing range 1 mm ... 800 mm 1)
Focus Approx. 1.2°
Type of light Visible red light
Light source LED 2)
Light spot size (distance) Ø 30 mm (800 mm)
Angle of dispersion Approx. 1.2°
Wave length 645 nm
Housing material Metal, Nickel-plated brass and PC
Optics material Plastic, PMMA
Enclosure rating IP67
Items supplied Fastening nuts (2 x)
Ambient operating temperature –25 °C ... +55 °C
Ambient temperature, storage –40 °C ... +70 °C



Warranty

We provide a 1-year warranty from the date of purchase for new products. Additionally, surplus / used items come with a 30-day warranty.

Delivery and Shipping

We aim to process orders within 5-7 business days. Shipping options vary by location with tracking provided; international shipping available with customs duties responsibility on customers.

SPARECRUX is NOT an authorized distributor for SICK SENSORS

Manufacturer Part Number (MPN)

6041811

Original Equipment Manufacturer

SICK SENSORS

PDF Product Datasheet

  • 100% Tested & Verified Products

  • GST Invoice Available

  • Warranty Included

  • Trusted by 5000+ Industrial Buyers

Functional principle - Photoelectric proximity sensor

Functional principle detail - Energetic

Dimensions (W x H x D) - 18 mm x 18 mm x 69.8 mm

Housing design (light emission) - Cylindrical

Housing length - 69.8 mm

Thread diameter (housing) - M18 x 1

Optical axis - Axial

Sensing range max. - 1 mm ... 1,100 mm 1)

Sensing range - 1 mm ... 800 mm 1)

Focus - Approx. 1.2°

Type of light - Visible red light

Light source - LED 2)

Light spot size (distance) - Ø 30 mm (800 mm)

Supply voltage UB - 10 V DC ... 30 V DC 1)

Ripple - ± 10 % 2)

Current consumption - 30 mA 3)

Switching output - PNP 4)

Switching mode - Light/dark switching 4)

Switching mode selector - Selectable via L/D control cable

Signal voltage PNP HIGH/LOW - Approx. VS – 1.8 V / 0 V

Output current Imax. - ≤ 100 mA

Response time - ≤ 0.5 ms 5)

Switching frequency - 1,000 Hz 6)

Connection type - Male connector M12, 4-pin

MTTFD - 1,884 years

DCavg - 0 %

EU declaration of conformity - ✔

UK declaration of conformity - ✔

ACMA declaration of conformity - ✔

Moroccan declaration of conformity - ✔

China RoHS - ✔

cULus certificate - ✔

Photobiological safety (DIN EN 62471) - ✔

ECLASS 5.0 - 27270903

ECLASS 5.1.4 - 27270903

ECLASS 6.0 - 27270903

ECLASS 6.2 - 27270903

ECLASS 7.0 - 27270903

ECLASS 8.0 - 27270903

ECLASS 8.1 - 27270903

ECLASS 9.0 - 27270903

ECLASS 10.0 - 27270904
