SPARECRUX is NOT an authorized distributor for SICK SENSORS

6028411 | SICK SENSORS | CM30-16BAP-KW1 Capacitive Proximity Sensors

₹ 11,538.51

₹ 9,778.40 (Excl. Tax)

●   Available for backorder, with an estimated lead time of 8 to 12 weeks.

Warranty

We provide a 1-year warranty from the date of purchase for new products. Additionally, surplus / used items come with a 30-day warranty.

Delivery and Shipping

We aim to process orders within 5-7 business days. Shipping options vary by location with tracking provided; international shipping available with customs duties responsibility on customers.

Enquire Now
Interested in this product? Submit your enquiry by entering your details.

Manufacturer Part Number (MPN)

6028411

Original Equipment Manufacturer

SICK SENSORS

Description
Housing Metric
Thread size M30 x 1.5
Diameter Ø 30 mm
Sensing range Sn 2 mm ... 16 mm
Safe sensing range Sa 11.52 mm
Installation type Flush
Switching frequency 10 Hz
Connection type Cable, 2-wire, 2 m 1)
Output function NC or NO
Supply voltage 20 V AC ... 250 V AC
Ripple ≤ 10 % 1)
Voltage drop ≤ 10 V DC 2)
Current consumption 10 mA 3)
Time delay before availability ≤ 100 ms
Hysteresis 4 % ... 20 %
Reproducibility

≤ 5 % 4)

 5)
Temperature drift (of Sr) ± 10 %
