6022487 | SICK SENSORS | VL18-4P6640 Photoelectric Retro-reflective Sensor

₹ 5,979.06

₹ 5,067.00 (Excl. Tax)

Get Best Price on WhatsApp

Product Description
Functional principle Photoelectric retro-reflective sensor
Dimensions (W x H x D) 18 mm x 18 mm x 78 mm
Housing design (light emission) Cylindrical
Housing length 78 mm
Thread diameter (housing) M18 x 1
Optical axis Axial
Sensing range max. 0.05 m ... 3.7 m 1)
Sensing range 0.05 m ... 3 m 1)
Focus Approx. 2.8°
Type of light Infrared light
Light source LED 2)
Light spot size (distance) Ø 150 mm (3 m)
Housing material Plastic, PBT/PC
Optics material Plastic, PMMA
Enclosure rating IP67
Ambient operating temperature –25 °C ... +70 °C



Warranty

We provide a 1-year warranty from the date of purchase for new products. Additionally, surplus / used items come with a 30-day warranty.

Delivery and Shipping

We aim to process orders within 5-7 business days. Shipping options vary by location with tracking provided; international shipping available with customs duties responsibility on customers.

SPARECRUX is NOT an authorized distributor for SICK SENSORS

Manufacturer Part Number (MPN)

6022487

Original Equipment Manufacturer

SICK SENSORS

PDF Product Datasheet

  • 100% Tested & Verified Products

  • GST Invoice Available

  • Warranty Included

  • Trusted by 5000+ Industrial Buyers

Functional principle - Photoelectric retro-reflective sensor

Dimensions (W × H × D) - 18 mm × 18 mm × 78 mm

Housing design (light emission) - Cylindrical

Housing length - 78 mm

Thread diameter (housing) - M18 × 1

Optical axis - Axial

Sensing range max. - 0.05 m ... 3.7 m

Sensing range - 0.05 m ... 3 m

Focus - Approx. 2.8°

Type of light - Infrared light

Light source - LED

Light spot size (distance) - Ø 150 mm (3 m)

Angle of dispersion - Approx. 2.8°

Adjustment - None

Supply voltage UB - 10 V DC ... 30 V DC

Ripple - ± 10 %

Current consumption - 30 mA

Switching output - PNP

Switching mode - Light/dark switching

Switching mode selector - Selectable via L/D control cable

Output current Imax. - ≤ 100 mA

Response time - ≤ 2 ms

Switching frequency - 250 Hz

Connection type - Male connector M12, 4-pin

Not applicable for this product

EU declaration of conformity - ✔

UK declaration of conformity - ✔

ACMA declaration of conformity - ✔

Moroccan declaration of conformity - ✔

China RoHS - ✔

cRUus certificate - ✔

ECLASS 5.0 - 27270902

ECLASS 5.1.4 - 27270902

ECLASS 6.0 - 27270902

ECLASS 6.2 - 27270902

ECLASS 7.0 - 27270902

ECLASS 8.0 - 27270902

ECLASS 8.1 - 27270902

ECLASS 9.0 - 27270902
