SPARECRUX is NOT an authorized distributor for FESTO

552938 | FESTO | Service Unit Combination MSB9

₹ 72,865.00

₹ 61,750.00 (Excl. Tax)

Warranty

We provide a 1-year warranty from the date of purchase for new products. Additionally, surplus / used items come with a 30-day warranty.

Delivery and Shipping

We aim to process orders within 5-7 business days. Shipping options vary by location with tracking provided; international shipping available with customs duties responsibility on customers.

Enquire Now
Interested in this product? Submit your enquiry by entering your details.

Manufacturer Part Number (MPN)

552938

Original Equipment Manufacturer

FESTO

Description
Specification Value
Size 9
Series MS
Type of Actuation Electric, Manual, Pneumatic
Actuator Lock Rotary knob with integrated lock
Mounting Position Optional, Vertical +/-5°
Grade of Filtration 0.01 µm ... 40 µm
Operating Pressure 0 MPa ... 2 MPa (0 bar ... 20 bar, 0 psi ... 290 psi)
Pressure Regulation Range 0.1 MPa ... 1.6 MPa (1 bar ... 16 bar, 14.5 psi ... 232 psi)
Standard Nominal Flow Rate 1400 l/min ... 18000 l/min (standardized to DIN 1343)
Pneumatic Connection, Port 3 G1, 1 NPT
Material Seals NBR
Material Housing Die-cast aluminium
Material Bowl Wrought aluminium alloy
