SPARECRUX is NOT an authorized distributor for SICK SENSORS

5337614 | SICK SENSORS | MAGNETIC TAPE

₹ 37,383.34

₹ 31,680.80 (Excl. Tax)


  Available for backorder, with an estimated lead time of 8 to 12 weeks.

Warranty

We provide a 1-year warranty from the date of purchase for new products. Additionally, surplus / used items come with a 30-day warranty.

Delivery and Shipping

We aim to process orders within 5-7 business days. Shipping options vary by location with tracking provided; international shipping available with customs duties responsibility on customers.


Enquire Now
Interested in this product? Submit your enquiry by entering your details.

Manufacturer Part Number (MPN)

5337614

Original Equipment Manufacturer

SICK SENSORS

Description

Accessory group Magnetic tapes
Description Magnetic tape, South is top side, adhesive, width 25 mm, length 50 m
Maximum energy product ≥ 9 kJ/m³
Remanence < 220 mT
Coercivity of the mag. flow density ≥ 170 kA/m
Coercivity of the mag. polarization ≥ 280 kA/m
Field line thickness via LS 150 g
Fire protection class B2 nach DIN 4102
Density 3.7 g/cm³
Magnetization Axial
Minimum bend radius 2 mm 1)
Ambient operating temperature max. ≤ +70 °C
Dimensions (W x H x L) 25 mm x 1.3 mm x 50 m



SICK SENSORS 5337614 MAGNETIC TAPE
SICK SENSORS

5337614 | SICK SENSORS | MAGNETIC TAPE

₹ 31,680.80
Accessory group Magnetic tapes
Description Magnetic tape, South is top side, adhesive, width 25 mm, length 50 m
Maximum energy product ≥ 9 kJ/m³
Remanence < 220 mT
Coercivity of the mag. flow density ≥ 170 kA/m
Coercivity of the mag. polarization ≥ 280 kA/m
Field line thickness via LS 150 g
Fire protection class B2 nach DIN 4102
Density 3.7 g/cm³
Magnetization Axial
Minimum bend radius 2 mm 1)
Ambient operating temperature max. ≤ +70 °C
Dimensions (W x H x L) 25 mm x 1.3 mm x 50 m
