SPARECRUX is NOT an authorized distributor for FESTO

530411 | FESTO | Valve Terminal MPA-FB-VI

₹ 40,753.96

₹ 34,537.25 (Excl. Tax)

Warranty

We provide a 1-year warranty from the date of purchase for new products. Additionally, surplus / used items come with a 30-day warranty.

Delivery and Shipping

We aim to process orders within 5-7 business days. Shipping options vary by location with tracking provided; international shipping available with customs duties responsibility on customers.

Enquire Now
Interested in this product? Submit your enquiry by entering your details.

Manufacturer Part Number (MPN)

530411

Original Equipment Manufacturer

FESTO

Description
Feature Description
Electrical Control Fieldbus
Electrical I/O System Yes
Terminal Type 32
Operating Medium Compressed air to ISO 8573-1:2010 [7:4:4]
Note on Operating and Pilot Medium Lubricated operation possible (in which case lubricated operation will always be required)
Media Temperature -5 °C ... 50 °C
Ambient Temperature -5 °C ... 50 °C
Storage Temperature -20 °C ... 40 °C
Relative Air Humidity Max. 90% at 40°C
Degree of Protection IP67
Corrosion Resistance Class CRC 1 - Low corrosion stress
Operating Pressure -0.09 MPa ... 1 MPa (-0.9 bar ... 10 bar)
Pilot Pressure 0.3 MPa ... 0.8 MPa (3 bar ... 8 bar)
LABS (PWIS) Conformity VDMA24364-B1/B2-L
CE Mark To EU EMC Directive, To EU Explosion Protection Directive (ATEX), In accordance with EU RoHS Directive
UKCA Marking To UK instructions for EMC, To UK EX instructions, To UK RoHS instructions
KC Mark KC-EMV
Approval RCM trademark, c UL us - Recognized (OL)
Explosion Protection Zone 1 (UKEX), Zone 2 (ATEX), Zone 21 (UKEX)
ATEX Category Gas II 3G
Explosion Protection Certification Outside the EU EPL Db (GB), EPL Gb (GB)
Explosion Ignition Protection Type for Gas Ex ec IIC T4 Gc X
Explosion Ambient Temperature -5 °C <= Ta <= +50 °C
Note on Materials RoHS-compliant
Valve Terminal Structure Modular, valve sizes can be mixed
Max. Number of Valve Positions 64
Max. Number of Pressure Zones 17
