SPARECRUX is NOT an authorized distributor for LEUZE ELECTRONIC

50129379 | LEUZE ELECTRONIC | Diffuse Sensor with Background Suppression

₹ 16,142.40

₹ 13,680.00 (Excl. Tax)

Warranty

We provide a 1-year warranty from the date of purchase for new products. Additionally, surplus / used items come with a 30-day warranty.

Delivery and Shipping

We aim to process orders within 5-7 business days. Shipping options vary by location with tracking provided; international shipping available with customs duties responsibility on customers.

Enquire Now
Interested in this product? Submit your enquiry by entering your details.

Manufacturer Part Number (MPN)

50129379

Original Equipment Manufacturer

LEUZE ELECTRONIC

Description
Specification Details
Series 3C
Operating Principle Diffuse reflection principle with background suppression
Application Detection of small parts
Special Version Small light spot (S)
Black-White Error < 10% up to 100 mm
Operating Range (White 90%) 0.005 … 0.2 m
Operating Range (Gray 18%) 0.01 … 0.15 m
Operating Range (Black 6%) 0.015 … 0.12 m
Operating Range Limit 0.005 … 0.2 m (typical operating range)
Adjustment Range 15 … 200 mm
Light Source LED, Red
Wavelength 650 nm
Transmitted-Signal Shape Pulsed
LED Group Exempt group (EN 62471)
Protective Circuits Polarity reversal protection, Short-circuit protection
Supply Voltage (UB) 10 … 30 V DC (incl. residual ripple)
Residual Ripple 0 … 15% of UB
Open-Circuit Current 0 … 15 mA
Number of Digital Switching Outputs 2
Output Type Digital switching output
Switching Element Transistor, PNP
Switching Principle Light switching
LEUZE ELECTRONIC

50129379 | LEUZE ELECTRONIC | Diffuse Sensor with Background Suppression

₹ 13,680.00
Specification Details
Series 3C
Operating Principle Diffuse reflection principle with background suppression
Application Detection of small parts
Special Version Small light spot (S)
Black-White Error < 10% up to 100 mm
Operating Range (White 90%) 0.005 … 0.2 m
Operating Range (Gray 18%) 0.01 … 0.15 m
Operating Range (Black 6%) 0.015 … 0.12 m
Operating Range Limit 0.005 … 0.2 m (typical operating range)
Adjustment Range 15 … 200 mm
Light Source LED, Red
Wavelength 650 nm
Transmitted-Signal Shape Pulsed
LED Group Exempt group (EN 62471)
Protective Circuits Polarity reversal protection, Short-circuit protection
Supply Voltage (UB) 10 … 30 V DC (incl. residual ripple)
Residual Ripple 0 … 15% of UB
Open-Circuit Current 0 … 15 mA
Number of Digital Switching Outputs 2
Output Type Digital switching output
Switching Element Transistor, PNP
Switching Principle Light switching
