30657 | FESTO | Semi-rotary Drive DSRL-32-180-P-FW

₹ 28,571.87

₹ 24,213.45 (Excl. Tax)

Warranty

We provide a 1-year warranty from the date of purchase for new products. Additionally, surplus / used items come with a 30-day warranty.

Delivery and Shipping

We aim to process orders within 5-7 business days. Shipping options vary by location with tracking provided; international shipping available with customs duties responsibility on customers.

Enquire Now
Interested in this product? Submit your enquiry by entering your details.

Manufacturer Part Number (MPN)

30657

Original Equipment Manufacturer

FESTO

Description
Parameter Value
Size 32
Cushioning Angle 1.2°
Rotation Angle Adjustment Range 0° ... 180°
Swivel Angle 0° ... 180°
Cushioning Elastic cushioning rings/plates at both ends
Mounting Position Optional
Mode of Operation Double-acting
Design Vane
Position Detection Without
Symbol 00991265
Operating Pressure 1.5 bar ... 8 bar
Max. Swivel Frequency at 0.6 MPa (6 bar, 87 psi) 3 Hz
Operating Medium Compressed air to ISO 8573-1:2010 [7:-:-]
LABS (PWIS) Conformity VDMA24364-B2-L
Ambient Temperature -10°C ... 60°C
Max. Axial Force 75 N
Max. Radial Force 200 N
Theoretical Torque at 0.6 MPa (6 bar, 87 psi) 10 Nm
Product Weight 1300 g
Type of Mounting With through-hole
Pneumatic Connection G1/8
Material - Covering PA-reinforced
Material - Drive Shaft Steel, Nickel-plated
Material - Seals NBR
Material - Housing Die-cast zinc
