2964500 | PHOENIX CONTACT | General Purpose Relay

₹ 5,235.64

₹ 4,436.98 (Excl. Tax)

Warranty

We provide a 1-year warranty from the date of purchase for new products. Additionally, surplus / used items come with a 30-day warranty.

Delivery and Shipping

We aim to process orders within 5-7 business days. Shipping options vary by location with tracking provided; international shipping available with customs duties responsibility on customers.

Enquire Now
Interested in this product? Submit your enquiry by entering your details.

Manufacturer Part Number (MPN)

2964500

Original Equipment Manufacturer

PHOENIX CONTACT

Description
Specification Details
Brand Phoenix Contact
Model / Part Number 2964500 (DEK-REL-G24/21)
Contact Configuration SPDT (1 changeover contact) :contentReference[oaicite:1]{index=1}
Coil Voltage 24 V DC :contentReference[oaicite:2]{index=2}
Contact Current Rating 6 A (limiting continuous current) :contentReference[oaicite:3]{index=3}
Maximum Switching Voltage 250 V AC/DC :contentReference[oaicite:4]{index=4}
Input Power Dissipation 0.22 W (nominal condition) :contentReference[oaicite:5]{index=5}
Operating Temperature Range -20 °C … +50 °C (operation) :contentReference[oaicite:6]{index=6}
Insulation / Surge Voltage Rated insulation voltage 250 V; Surge voltage 6 kV; Test voltage between coil & contact 4 kV AC (1 min) :contentReference[oaicite:7]{index=7}
Dimensions (W × H × D) 6.2 mm wide × 80 mm height × 56 mm depth :contentReference[oaicite:8]{index=8}
Mounting Type DIN-rail (35 mm) mounting :contentReference[oaicite:9]{index=9}
Contact Material AgSnO (Silver Tin Oxide) :contentReference[oaicite:10]{index=10}
Country of Origin China (CN) :contentReference[oaicite:11]{index=11}
Datasheet Reference 2964500 (PDF) :contentReference[oaicite:12]{index=12}
