SPARECRUX is NOT an authorized distributor for WAGO

285-635 | WAGO | 2-Conductor Through Terminal Block, 35mm², Integrated End Plate, Gray

₹ 1,613.72

₹ 1,367.56 (Excl. Tax)


Warranty

We provide a 1-year warranty from the date of purchase for new products. Additionally, surplus / used items come with a 30-day warranty.

Delivery and Shipping

We aim to process orders within 5-7 business days. Shipping options vary by location with tracking provided; international shipping available with customs duties responsibility on customers.


Enquire Now
Interested in this product? Submit your enquiry by entering your details.

Manufacturer Part Number (MPN)

285-635

Original Equipment Manufacturer

WAGO

Description

Property Value
Connection Technology CAGE CLAMP®
Actuation Type Operating Tool
Connectable Conductor Materials Copper
Nominal Cross-Section 35 mm²
Solid Conductor 6 … 35 mm² / 10 … 2 AWG
Fine-Stranded Conductor 6 … 35 mm² / 10 … 2 AWG
Strip Length 23 mm / 0.91 inches
Wiring Direction Front-entry wiring
Width 16 mm / 0.63 inches
Height 100 mm / 3.937 inches
Mounting Type DIN-35 rail
Mounting (Note) Only suitable for DIN 35 x 15 rail
Marking Level Center/side marking
Color Gray
Material Group I
Insulation Material (Main Housing) Polyamide (PA66)
Flammability Class per UL94 V0
Fire Load 1.078 MJ
Weight 87.3 g
WAGO

285-635 | WAGO | 2-Conductor Through Terminal Block, 35mm², Integrated End Plate, Gray

₹ 1,367.56
Property Value
Connection Technology CAGE CLAMP®
Actuation Type Operating Tool
Connectable Conductor Materials Copper
Nominal Cross-Section 35 mm²
Solid Conductor 6 … 35 mm² / 10 … 2 AWG
Fine-Stranded Conductor 6 … 35 mm² / 10 … 2 AWG
Strip Length 23 mm / 0.91 inches
Wiring Direction Front-entry wiring
Width 16 mm / 0.63 inches
Height 100 mm / 3.937 inches
Mounting Type DIN-35 rail
Mounting (Note) Only suitable for DIN 35 x 15 rail
Marking Level Center/side marking
Color Gray
Material Group I
Insulation Material (Main Housing) Polyamide (PA66)
Flammability Class per UL94 V0
Fire Load 1.078 MJ
Weight 87.3 g
