2080-RPL24RTB | ALLEN BRADLEY | Micro800 Replacement 24-Point Terminal Block
₹ 3,334.28
₹ 2,825.66 (Excl. Tax)
Couldn't load pickup availability
Warranty
Warranty
We provide a 1-year warranty from the date of purchase for new products. Additionally, surplus / used items come with a 30-day warranty.
Delivery and Shipping
Delivery and Shipping
We aim to process orders within 5-7 business days. Shipping options vary by location with tracking provided; international shipping available with customs duties responsibility on customers.
Manufacturer Part Number (MPN)
2080-RPL24RTB
Original Equipment Manufacturer
ALLEN BRADLEY
Description
Description
Technical Data for Allen-Bradley 2080-RPL24RTB
| Specification | Details |
| Product Type | Replacement Removable Terminal Block (RTB) |
| Compatibility | Micro800 24-point controllers |
| Number of Terminals | 24 |
| Wire Size | 0.14…1.5 mm² (26…16 AWG) solid or stranded copper wire rated @ 90°C (194°F), or greater, insulation maximum |
| Terminal Screw Torque | 0.22…0.25 Nm (1.95…2.21 in-lb) (using a 2.5 mm (0.10 in.) flat-blade screwdriver) |
| Operating Temperature Range | -20…65°C (-4…149°F) |
| Storage Temperature Range | -40…85°C (-40…185°F) |
| Relative Humidity | 5…95% non-condensing |
| Certifications | c-UL-us Listed; CE Marked; RCM; KC |
