18220 | FESTO | Valve Terminal CPV18-VI

₹ 72,865.00

₹ 61,750.00 (Excl. Tax)

Warranty

We provide a 1-year warranty from the date of purchase for new products. Additionally, surplus / used items come with a 30-day warranty.

Delivery and Shipping

We aim to process orders within 5-7 business days. Shipping options vary by location with tracking provided; international shipping available with customs duties responsibility on customers.

Enquire Now
Interested in this product? Submit your enquiry by entering your details.

Manufacturer Part Number (MPN)

18220

Original Equipment Manufacturer

FESTO

Description


Specification Details
Terminal type 10
Operating medium Compressed air to ISO 8573-1:2010 [7:4:4]
Note on operating and pilot medium Lubricated operation possible (in which case lubricated operation will always be required)
Media temperature -5 °C ... 50 °C
Ambient temperature -5 °C ... 50 °C
Storage temperature -20 °C ... 40 °C
Degree of protection IP65
Corrosion resistance class (CRC) 1 - Low corrosion stress
Explosion protection certification outside the EU EPL Gc (GB), NEC 500 Class I, Div. 2
Explosion ignition protection type for gas Ex ec IIC T4 Gc X
Explosion ambient temperature -5 °C <= Ta <= +50 °C
Note on materials RoHS-compliant
Valve terminal structure Fixed grid
Max. number of valve positions 8
Max. number of valve functions 16
Max. number of pressure zones 2
Type of actuation Electric
Valve function 2x2/2-way, monostable, closed
FESTO

18220 | FESTO | Valve Terminal CPV18-VI

₹ 61,750.00


Specification Details
Terminal type 10
Operating medium Compressed air to ISO 8573-1:2010 [7:4:4]
Note on operating and pilot medium Lubricated operation possible (in which case lubricated operation will always be required)
Media temperature -5 °C ... 50 °C
Ambient temperature -5 °C ... 50 °C
Storage temperature -20 °C ... 40 °C
Degree of protection IP65
Corrosion resistance class (CRC) 1 - Low corrosion stress
Explosion protection certification outside the EU EPL Gc (GB), NEC 500 Class I, Div. 2
Explosion ignition protection type for gas Ex ec IIC T4 Gc X
Explosion ambient temperature -5 °C <= Ta <= +50 °C
Note on materials RoHS-compliant
Valve terminal structure Fixed grid
Max. number of valve positions 8
Max. number of valve functions 16
Max. number of pressure zones 2
Type of actuation Electric
Valve function 2x2/2-way, monostable, closed
