1734-IE4SK | ALLEN BRADLEY | POINT Guard I/O 4-Channel Safety Analog Input Module, Conformal Coated
₹ 116,059.64
₹ 98,355.63 (Excl. Tax)
Couldn't load pickup availability
Warranty
Warranty
We provide a 1-year warranty from the date of purchase for new products. Additionally, surplus / used items come with a 30-day warranty.
Delivery and Shipping
Delivery and Shipping
We aim to process orders within 5-7 business days. Shipping options vary by location with tracking provided; international shipping available with customs duties responsibility on customers.
Manufacturer Part Number (MPN)
1734-IE4SK
Original Equipment Manufacturer
ALLEN BRADLEY
Description
Description
|
Specification |
Description |
|
Input Channels |
4 differential inputs |
|
Input Signal Range |
-10V to +10V DC, 0…20 mA, or 4…20 mA, selectable per channel |
|
Resolution |
12 bits |
|
Conversion Rate |
~10 ms per channel |
|
Accuracy |
±0.1% full scale at 25 °C (77 °F) |
|
Input Impedance |
Voltage mode: ~220 kΩ; Current mode: ~100 Ω |
|
Safety Ratings |
SIL 3 (IEC 61508), PLe (ISO 13849-1) |
|
Power Consumption |
1.5 W max |
|
Power Dissipation |
5.1 BTU/hr max |
|
Operating Temperature Range |
-20…55 °C (-4…131 °F) |
|
Storage Temperature Range |
-40…85 °C (-40…185 °F) |
|
Dimensions (HxWxD) |
56.6 x 12 x 75.5 mm (2.23 x 0.47 x 2.97 in.) |
|
Certifications |
CE, UL, c-UL, Class I Division 2, ATEX Zone 2, IECEx |
