170933 | FESTO | DFM-32-50-P-A-KF Guided Drive

₹ 42,480.00

₹ 36,000.00 (Excl. Tax)

Warranty

We provide a 1-year warranty from the date of purchase for new products. Additionally, surplus / used items come with a 30-day warranty.

Delivery and Shipping

We aim to process orders within 5-7 business days. Shipping options vary by location with tracking provided; international shipping available with customs duties responsibility on customers.

Enquire Now
Interested in this product? Submit your enquiry by entering your details.

Manufacturer Part Number (MPN)

170933

Original Equipment Manufacturer

FESTO

Description



Parameter Specification
Brand Festo
Model 170933
Type Guided Pneumatic Cylinder
Series DFM
Standard ISO guided drive unit
Operation Double-acting
Bore Diameter 32 mm
Stroke Length 50 mm
Operating Mode Yoke type drive unit
Guide Type Recirculating ball bearing guide (KF)
Mounting Position Any
Cushioning Elastic cushioning rings/plates at both ends
Operating Pressure 1.5 – 10 bar (0.15 – 1 MPa)
Max Speed 0.8 m/s
Pneumatic Medium Compressed air (ISO 8573-1:2010 [7:4:4])
Port Size G1/8
Position Detection Proximity sensor ready
Corrosion Resistance CRC 0 (no corrosion stress)
Cleanroom Class ISO Class 6 (ISO 14644-1)
LABS Compliance VDMA 24364-B1/B2-L
Material Aluminium housing, stainless steel piston rod
Weight ~2.0 kg
