156565 | FESTO | Compact Cylinder ADVU-63-50-P-A

₹ 12,503.82

₹ 10,596.46 (Excl. Tax)

Warranty

We provide a 1-year warranty from the date of purchase for new products. Additionally, surplus / used items come with a 30-day warranty.

Delivery and Shipping

We aim to process orders within 5-7 business days. Shipping options vary by location with tracking provided; international shipping available with customs duties responsibility on customers.

Enquire Now
Interested in this product? Submit your enquiry by entering your details.

Manufacturer Part Number (MPN)

156565

Original Equipment Manufacturer

FESTO

Description
Parameter Value
Stroke 50 mm
Piston diameter 63 mm
Piston rod thread M8
Cushioning Elastic cushioning rings/plates at both ends
Mounting position Optional
Mode of operation Double-acting
Piston-rod end Female thread
Design Piston, Piston rod
Ambient temperature -20 °C ... 80 °C
Impact energy in end positions 0.7 J
Theoretical force at 0.6 MPa (return stroke) 1750 N
Theoretical force at 0.6 MPa (advance stroke) 1870 N
Moving mass for 0 mm stroke 134 g
Additional moving mass per 10 mm stroke 16 g
Basic weight for 0 mm stroke 1059 g
Additional weight per 10 mm stroke 107 g
