152616 | FESTO | Pressure Switch PEV-W-S-LED-GH
₹ 5,120.62
₹ 4,339.51 (Excl. Tax)
Couldn't load pickup availability
Warranty
We provide a 1-year warranty from the date of purchase for new products. Additionally, surplus / used items come with a 30-day warranty.
Delivery and Shipping
We aim to process orders within 5-7 business days. Shipping options vary by location with tracking provided; international shipping available with customs duties responsibility on customers.
RCM trademark, CE mark (see declaration of conformity), To EU EMC Directive, In accordance with EU RoHS Directive, UKCA marking (see declaration of conformity), To UK instructions for EMC, To UK RoHS instructions
Note on materials
RoHS-compliant
Measured variable
Relative pressure
Measurement method
Pneumatic/electric pressure transducer
Pressure measuring range
2 bar ... 8 bar
Operating pressure
0 bar ... 8 bar
Max. overload pressure
20 bar
Operating medium
Compressed air to ISO 8573-1:2010 [7:-:-]
Note on operating and pilot medium
Lubricated operation possible (in which case lubricated operation will always be required)
Media temperature
0 °C ... 60 °C
Ambient temperature
0 °C ... 60 °C
Switching element function
Changeover switch
Hysteresis
0.5 bar ... 2 bar
Max. switching frequency
3 Hz
Max. output current
2500 mA
Operational voltage range DC
10 V ... 30 V
Electrical connection 1, connection type
Plugs
Electrical connection 1, connector system
M8x1, A-coded, to EN 61076-2-104, Diameter 8 mm, A-coded to EN 61076-2-104
Electrical connection 1, number of connections/cores
4
Electrical connection 1, type of mounting
Snap-locking, Screw-type lock, Not rotatable
Electrical connection 1, compatible type of mounting
Compatible with latching lock, Compatible with rotatable screw-type lock
Type of mounting
With through-hole, With H-rail
Mounting position
Optional
Pneumatic connection
M5
Product weight
56 g
Material housing
PET, POM
Material membrane
NBR
Switching status indication
Yellow LED
Setting range threshold value
2 bar ... 8 bar
Degree of protection
IP65
Corrosion resistance class CRC
2 - Moderate corrosion stress
