SPARECRUX is NOT an authorized distributor for FESTO

151165 | FESTO | One-way Flow Control Valve GRLA-1/8-B

₹ 536.42

₹ 454.59 (Excl. Tax)

Warranty

We provide a 1-year warranty from the date of purchase for new products. Additionally, surplus / used items come with a 30-day warranty.

Delivery and Shipping

We aim to process orders within 5-7 business days. Shipping options vary by location with tracking provided; international shipping available with customs duties responsibility on customers.

Enquire Now
Interested in this product? Submit your enquiry by entering your details.

Manufacturer Part Number (MPN)

151165

Original Equipment Manufacturer

FESTO

Description
Property Specification
Valve function Exhaust air one-way flow control function
Pneumatic connection, port 1 G1/8
Pneumatic connection, port 2 G1/8
Adjustment component Slotted head screw
Type of mounting Screw-in
Standard nominal flow rate in flow control direction 340 l/min
Standard nominal flow rate in blocked direction 260 l/min ... 420 l/min
Ambient temperature -10 °C ... 60 °C
Maritime classification See certificate
Explosion protection Zone 1 (ATEX), Zone 2 (ATEX),
Zone 21 (ATEX), Zone 22 (ATEX)
The information in the certificate must be observed!
Mounting position Optional
Symbol 00991452
Operating pressure complete temperature range 0.3 bar ... 10 bar
Standard flow rate in flow control direction 0.6->0 MPa 615 l/min
Standard flow rate in non-return direction 0.6->0 MPa 470 l/min ... 760 l/min
Operating medium Compressed air to ISO 8573-1:2010 [7:4:4]
Note on operating and pilot medium Lubricated operation possible (lubricated operation always required if used)
LABS (PWIS) conformity VDMA24364-B1/B2-L
Cleanroom class Class 4 according to ISO 14644-1
Media temperature -10 °C ... 60 °C
Max. tightening torque 6 Nm
Product weight 28 g
Material screwed plug Wrought aluminium alloy
Note on materials RoHS-compliant
Material seals NBR
Material adjusting screw Brass
Material swivel fitting Die-cast zinc
