SPARECRUX is NOT an authorized distributor for FESTO

150261 | FESTO | Vacuum Switch VPEV-1/8

₹ 6,690.29

₹ 5,669.74 (Excl. Tax)

Warranty

We provide a 1-year warranty from the date of purchase for new products. Additionally, surplus / used items come with a 30-day warranty.

Delivery and Shipping

We aim to process orders within 5-7 business days. Shipping options vary by location with tracking provided; international shipping available with customs duties responsibility on customers.

Enquire Now
Interested in this product? Submit your enquiry by entering your details.

Manufacturer Part Number (MPN)

150261

Original Equipment Manufacturer

FESTO

Description
Parameter Value
Conforms to Standard EN 60947-5-1
Symbol 00991471
Approval CCC
CE Mark To EU Low Voltage Directive
UKCA Marking To UK regulations for electrical equipment
Explosion Protection Certified for:Zone 1 (ATEX)Zone 2 (ATEX)Zone 21 (ATEX)Zone 22 (ATEX)Observe certificate
Note on Materials RoHS-compliant
Measured Variable Relative pressure
Measurement Method Pneumatic/electric pressure transducer
Pressure Measuring Range -0.1 MPa to 0.16 MPa-1 bar to 1.6 bar-14.5 psi to 23.2 psi
Operating Pressure -0.1 MPa to 0.16 MPa-1 bar to 1.6 bar
Operating Medium Compressed air to ISO 8573-1:2010 [7:4:4]
Note on Operating Medium Lubricated operation possible (must remain lubricated once started)
Media Temperature Range -20 °C to +80 °C
Ambient Temperature Range -20 °C to +80 °C
Switching Element Function Changeover switch
Max. Switching Frequency 3 Hz
Max. Switching Output Voltage (AC) 250 V
Max. Switching Output Voltage (DC) 125 V
Max. Output Current 5000 mA
Min. Load Current 1 mA at 24 V10 mA at 10 V100 mA at 5 V
Utilisation Category – Inductive Load AC-14, DC-13
Utilisation Category – Resistive Load AC-12, DC-12
Electrical Connection Type A
Plug Type To DIN 43650
Design Square
Type of Mounting With through-hole
Mounting Position Optional
Pneumatic Connection G1/8
Switching Status Indication Yellow LED
Product Weight 240 g
Material – Housing Wrought aluminium alloy
Material – Switch Contact Silver
