140M-F8N-C32 | ALLEN BRADLEY | Motor Circuit Protector Circuit-Breaker, F Frame, 32 A, High Performance

₹ 16,284.54

₹ 13,800.46 (Excl. Tax)


Warranty

We provide a 1-year warranty from the date of purchase for new products. Additionally, surplus / used items come with a 30-day warranty.

Delivery and Shipping

We aim to process orders within 5-7 business days. Shipping options vary by location with tracking provided; international shipping available with customs duties responsibility on customers.


Enquire Now
Interested in this product? Submit your enquiry by entering your details.

Manufacturer Part Number (MPN)

140M-F8N-C32

Original Equipment Manufacturer

ALLEN BRADLEY

Description

Specification Details
Catalog Number 140M-F8N-C32
Product Type Motor Protection Circuit Breaker
Adjustable Thermal Current Range 23 to 32 A
Magnetic Trip Current Fixed at 13 times the maximum setting current (13 x Ie)
Frame Size F
Rated Operational Voltage (Ue) Up to 690V AC
Rated Short-Circuit Breaking Capacity 65 kA at 400V AC
Mounting Standard busbar mount, top feed
Control Element Type Standard rotary knob
Certifications UL 508 - Manual Motor Controller; UL 508 Self-Protected (Type E) Combination Motor Controller
ALLEN BRADLEY

140M-F8N-C32 | ALLEN BRADLEY | Motor Circuit Protector Circuit-Breaker, F Frame, 32 A, High Performance

₹ 13,800.46
Specification Details
Catalog Number 140M-F8N-C32
Product Type Motor Protection Circuit Breaker
Adjustable Thermal Current Range 23 to 32 A
Magnetic Trip Current Fixed at 13 times the maximum setting current (13 x Ie)
Frame Size F
Rated Operational Voltage (Ue) Up to 690V AC
Rated Short-Circuit Breaking Capacity 65 kA at 400V AC
Mounting Standard busbar mount, top feed
Control Element Type Standard rotary knob
Certifications UL 508 - Manual Motor Controller; UL 508 Self-Protected (Type E) Combination Motor Controller
