1395690 | FESTO | Suction Cup Complete VASB-30-1/8-PUR-B

₹ 783.67

₹ 664.13 (Excl. Tax)


Warranty

We provide a 1-year warranty from the date of purchase for new products. Additionally, surplus / used items come with a 30-day warranty.

Delivery and Shipping

We aim to process orders within 5-7 business days. Shipping options vary by location with tracking provided; international shipping available with customs duties responsibility on customers.


Enquire Now
Interested in this product? Submit your enquiry by entering your details.

Manufacturer Part Number (MPN)

1395690

Original Equipment Manufacturer

FESTO

Description

Parameter Value
Height compensator for suction cup 13.9 mm
Nominal size 3 mm
Suction cup diameter 30 mm
Suction cup volume 6.18 cm³
Effective suction diameter 24.8 mm
Position of connection Top
Mounting position Optional
Symbol 00991485
Suction cup shape Round bellows 1.5 convolutions
Operating pressure -0.095 MPa ... 0 MPa
-0.95 bar ... 0 bar
-13.775 psi ... 0 psi
Nominal operating pressure -0.07 MPa
-0.7 bar
-10.15 psi
Operating medium Atmospheric air based on ISO 8573-1:2010 [7:-:-]
Corrosion resistance class (CRC) 2 - Moderate corrosion stress
LABS (PWIS) conformity VDMA24364-A1-L
Ambient temperature -20 °C ... 60 °C
Holding force at nominal operating pressure 34 N
Product weight 14 g
Type of mounting Via vacuum port
Vacuum connection G1/8
Colour Blue
Shore hardness 60 ± 5
Material screwed plug Brass
