1376312 | FESTO | ISO Cylinder DSBC-50-320-PPSA-N3

₹ 5,719.77

₹ 4,847.26 (Excl. Tax)


Warranty

We provide a 1-year warranty from the date of purchase for new products. Additionally, surplus / used items come with a 30-day warranty.

Delivery and Shipping

We aim to process orders within 5-7 business days. Shipping options vary by location with tracking provided; international shipping available with customs duties responsibility on customers.


Enquire Now
Interested in this product? Submit your enquiry by entering your details.

Manufacturer Part Number (MPN)

1376312

Original Equipment Manufacturer

FESTO

Description

Parameter Specification
Stroke 320 mm
Piston diameter 50 mm
Piston rod thread M16×1.5
Cushioning Self-adjusting pneumatic end-position cushioning
Cushioning length 22 mm
Mounting position Optional
Standard compliance ISO 15552
Piston-rod end Male thread
Design Piston, Piston rod, Profile barrel
Position detection Via proximity switch
Symbol 00992970
Variants Piston rod at one end
Operating pressure 0.04 MPa ... 1.2 MPa (0.4 bar ... 12 bar)
Mode of operation Double-acting
Operating medium Compressed air (ISO 8573-1:2010 [7:4:4])
Note on operating medium Lubricated operation possible (then always required)
Corrosion resistance class (CRC) 2 – Moderate corrosion stress
LABS (PWIS) conformity VDMA24364-B1/B2-L
Cleanroom class Class 5 (ISO 14644-1)
Ambient temperature -20 °C ... 80 °C
Impact energy in end positions 1 J
Theoretical force at 0.6 MPa, advance stroke 1178 N
Theoretical force at 0.6 MPa, return stroke 990 N
Moving mass 1165 g
Moving mass (0 mm stroke) 365 g
Additional moving mass per 10 mm stroke 25 g
Product weight 2982 g
Basic weight (0 mm stroke) 1190 g
Additional weight per 10 mm stroke 56 g
Type of mounting Via female thread, with accessories
Pneumatic connection G1/4
Note on materials RoHS-compliant
