1113627 | SICK SENSORS | SGS4-F076P7PS2T01 Automation Light Grid

₹ 71,304.10

₹ 60,427.20 (Excl. Tax)


  Available for backorder, with an estimated lead time of 8 to 12 weeks.

Warranty

We provide a 1-year warranty from the date of purchase for new products. Additionally, surplus / used items come with a 30-day warranty.

Delivery and Shipping

We aim to process orders within 5-7 business days. Shipping options vary by location with tracking provided; international shipping available with customs duties responsibility on customers.


Enquire Now
Interested in this product? Submit your enquiry by entering your details.

Manufacturer Part Number (MPN)

1113627

Original Equipment Manufacturer

SICK SENSORS

Description

Specification Details
Sensor principle Sender/receiver
Minimum detectable object (MDO) Cross beam, 25 mm
Beam separation 40 mm
Optical light exit Flat
Number of beams 20
Detection height 760 mm
Parameterization Teach-in button
Cross beam/parallel beam Cross beam active
Light source Infrared light
Wavelength 950 nm
Supply voltage Vs DC24 V, ± 20 %
Power consumption receiver ≤ 70 mA
Output current Imax. 100 mA
Output load, capacitive 100 nF



SICK SENSORS 1113627 SGS4-F076P7PS2T01 Automation Light Grid
SICK SENSORS

1113627 | SICK SENSORS | SGS4-F076P7PS2T01 Automation Light Grid

₹ 60,427.20
Specification Details
Sensor principle Sender/receiver
Minimum detectable object (MDO) Cross beam, 25 mm
Beam separation 40 mm
Optical light exit Flat
Number of beams 20
Detection height 760 mm
Parameterization Teach-in button
Cross beam/parallel beam Cross beam active
Light source Infrared light
Wavelength 950 nm
Supply voltage Vs DC24 V, ± 20 %
Power consumption receiver ≤ 70 mA
Output current Imax. 100 mA
Output load, capacitive 100 nF
